Show hosts in the map

Icinga Web Modules Visualization, Metrics & Reporting
1

Hello, I have a problem with hosts in module map

Icinga 2 installed on CentOS 8

my configuration

/etc/icingaweb2/modules/map/config.ini

[provider]
osm_provider = “OpenStreetMap”

[options]
location_lat = “vars.location_lat”
location_lon = “vars.location_lon”

[openstreetmap]
url = “https://{s}.tile.openstreetmap.org/{z}/{x}/{y}.png”
attribution = “Map data © OpenStreetMap contributors”

For test, my configuration

/etc/icinga2/conf.d/hosts.conf

object Host “example_host” {
import “generic-host”
address = “192.168.1.1”
vars.location_lat = 40.7128
vars.location_lon = -74.0060
}

But, I don’t have any hosts in map.
Already check for erros on
sudo icinga2 daemon -C
Verify file permissions with
ls -l /etc/icingaweb2/modules/map/config.ini

with command
icinga2 object list --type Host --name example_host
…

  • vars
    • location_lat = 40.712800
      % = modified in ‘/etc/icinga2/conf.d/hosts.conf’, lines 57:5-57:31
    • location_lon = -74.006000
      % = modified in ‘/etc/icinga2/conf.d/hosts.conf’, lines 58:5-58:32
  • volatile = false
  • zone = “”

…

Any help, maybe I forget something?

Thanks

2

how did you get this config of the map module? this seems to be a bit off.
If you use this maps module:

it uses:

vars.geolocation = “,”

see:
